The ORIGINAL Cold Galvanizing Compound

ZRC Galvilite Large

ZRC® Cold Galvanizing Compound

  • THE original cold galvanizing compound
  • Fifty years of proven success
  • True galvanic protection
  • Equivalent to hot-dip galvanizing
  • Single-component - Battleship gray finish
  • Apply by brush, roller or spray
  • Meets VOC standards in all 50 states
  • Available in clog-free aerosol form
Joomla SEO by AceSEF

Floating Salmon Pens

ZRC used on salmon fish farm pens in the hostile saltwater environment of Lubec Harbor, ME.

  • Specifications
  • Characteristics
  • Application
  • Technical Data & SDS
  • How To Buy
TYPE: Single pack, premixed, ready-to-apply liquid organic zinc compound

GENERAL PROPERTIES: ZRC® is a high-quality cold galvanizing compound based on a trade secret organic binder which affords true galvanic anti-corrosion protection to metals. The dried film of ZRC is 95% metallic zinc. Because of the uniqueness of the formulation, ZRC is the only coating of its type to be recognized under the Component Program of Underwriter's Laboratories, Inc.

RECOMMENDED USES: ZRC is widely used without topcoat in place of hot-dip galvanizing. Also used as a high-performance base coat with a variety of topcoats. Used for repair of damaged hot-dip galvanizing Galvalume® and zinc metallizing, regalvanizing worn hot-dip galvanizing, repair of weldments, and repair of damaged inorganic zinc coatings. Excellent for long-term protection of structural steel, water and waste facilities, power plants, transmission towers and antennae, steel decking and bridges, and numerous OEM uses.

SUBSTRATES: Apply to properly prepared carbon steel, cast iron, hot-dip galvanized, and aluminum surfaces.
NOT RECOMMENDED FOR: Contact with potable water, strong acids or strong alkalis

TEMPERATURE RESISTANCE (non-immersion):
Continuous: 350°F max/177°C max
Non-Continuous: 750°F max/399°C max

SALT FOG EXPOSURE: 2,852 Hours (ASTM B117)

PROHESION/QUV EXPOSURE: 2,000 Hours (ASTM D5894)

VOC: 3.3 Lbs/gal (385 gms/Ltr) (ASTM D3960)

PROJECT SPECIFICATIONS:

- Suggested Specification Verbiage

- CSI Format Specification

- Outline Specification

SOLIDS CONTENT: % Solids of Liquid Coating — 86% (by weight)/52% (by volume)

METALLIC ZINC CONTENT: 95% by weight in dry film. Zinc Dust used specified as ASTM D 520 Type III.

RECOMMENDED FILM THICKNESS PER COAT:
Wet: 3.0 mils (76 µ) Dry: 1.5 mils (38 µ)

THEORETICAL COVERAGE:
400 Ft ²/Gal @ 1.5 mil dry film thickness
3.4 M ² /Kg @ 38 µ dry film thickness

FINISH: Flat light grey

FLASH POINT: 104°F (40°C) (SETA method, ASTM D3278)

WEIGHT PER GALLON: 24 Lbs (ASTM D1475)

MASS DENSITY: 2.797 gms/cm cubed

VISCOSITY: 1900 cps. Brookfield RVT spindle #5 @ 100 RPM, 25°C

PENCIL HARDNESS: 2H (ASTM D3363)

IMPACT RESISTANCE: Greater than 30 inch lbs.
(Extrusion) (per ASTM-D2794)

ELECTRICAL CONDUCTIVITY: 73 million ohms per square @ 3 mils dry (resistivity).

ABRASION RESISTANCE: 11.5 liters per dry mil (tested at 3 dry mils) (per ASTM-D968-51)
POT LIFE: At least 24 hours

WATER IMMERSION: 100° F (38° C)

SURFACE PREPARATION: Dependent upon surface conditions and intended service. Typical examples are as follows:

Grease & Oils Solvent to clean SSPC-SP1
Rust Scale Power tool clean to SSPC-SP3 or SSPC-SP11 (SIS St 2 or 3)
Mill Scale, Paint or Heavy Rust Sandblast to SSPC-SP6 (commercial)
(SIS Sa 2)
Water Immersion (100°F (38°C) Maximum) Sandblast to SSPC-SP10(near white)
(SIS Sa 2.5)

APPLICATION METHODS

BRUSH/ROLLER/AEROSOL: Apply as received in container.

SPRAY (low pressure compressor type):
Atomized Air Pressure 50 Lbs (1.3 kg/cm²)
Fluid Pressure 15 to 20 Lbs (0.4-0.6 kg/cm²)
Orifice of Tip 0.080 inches (0.20 cm)
Viscosity Reduction 4:1 ZRC:XXX Thinner -OR- 16:1 ZRC:Xylol/Xylene

SPRAY (airless type):
Pump 30:1 Ratio
Hose 1/2" (1.3 cm)(I.D.) Airless Type
Orifice of Tip 60° - .026 in. (0.07 cm)
Type of Tip Tungsten carbide, reversing
Filter Screens Complete removal is recommended. However, if screens are employed, use no less than 30 mesh.
Viscosity No reduction required.
Recommended Procedure Connect hose directly to pump ensuring a hose length of 50 ft. max. Use least procedure possible. Start at 1500 lbs. (680 kg) and increase as required for good spraying.

CLEAN UP: ZRC XXX Thinner or Xylol/Xylene

DRY TIME (set to touch): When ambient air dried, 20-30 minutes @ 1.5 mil (38 µ) thickness

RECOAT TIME (2nd coat of ZRC): 12 hours. Under certain conditions, recoat time can be reduced. Please contact manufacturer for specifics.

TOPCOATING: After 24-48 hours, ZRC may be topcoated with acrylic, chlorinated rubber, epoxy, urethane or vinyl type products. DO NOT TOPCOAT WITH ALKYD, ALKYD-MODIFIED ACRYLIC, OR LACQUER TYPE PRODUCTS.
PURCHASING INFORMATION: ZRC can be ordered directly from our factory (United States only) or through authorized distributors. To place an order or locate a local distributor please contact us at 1-800-831-3275 (domestic US only) or use our Online Inquiry Form. All our products are non-hazardous for regular UPS Ground and common-carrier transportation and can be shipped immediately from stock on MasterCard, Visa or American Express.

PRICING: Prices may be obtained from ZRC Customer Service at 1-800-831-3275 (domestic US only), 1-781-319-0400, by fax at 1-781-319-0404 or Online Inquiry Form.

AVAILABILITY: ZRC is stocked worldwide through authorized distributors.


Size Part No. Weight/Unit Units/Case
3.5 gallon pails 10004 90 lbs (40.8 kg) 1
1 gallon can 10003 25 lbs (13.3 kg) 2
1 quart can 10002 6 lbs (2.7 kg) 6
1/2 pint can 10001 1.5 lbs (0.68 kg) 24
12 oz. Aerosol can 10000 1 lb (.45 kg) 24

To the best of our knowledge the technical data contained herein are true and accurate at the date of issuance and are subject to change without prior notice. User must contact ZRC Worldwide to verify correctness before specifying or ordering. No guarantee of accuracy is given or implied. We guarantee our products to conform to ZRC Worldwide quality control. We assume no responsibility for coverage, performance, or injuries resulting from use. Liability, if any is limited to replacement of products. Prices and cost data, if shown, are subject to change without prior notice. NO OTHER WARRANTY OR GUARANTEE OF ANY KIND is made by ZRC Worldwide, EXPRESS OR IMPLIED, STATUTORY, BY OPERATION OF LAW, OR OTHERWISE, INCLUDING MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
