    ZRC Galvilite® Galvanizing Repair

    Designed specifically for field and shop repair of hot-dip galvanization, ZRC Galvilite® exceeds galvanizing repair specifications like ASTM Des. A 780, SSPC-Paint 20, and DOD-P-21035A.

    Buy Now Contact A Dealer
    Order now and we’ll ship within 24 hours!
    Buy Now

    At-A-Glance: ZRC Galvilite Galvanizing Repair

    ZRC Galvilite Galvanizing Repair is a high-quality cold galvanizing compound based on a trade secret organic binder which affffords true galvanic anti-corrosion protection to metals. Galvilite® is designed specifically for field and shop repair of hot-dip galvanizing. It is manufactured with the highest purity ASTM D520 Type III zinc dust. It meets VOC standards in all 50 states, exceeds galvanizing repair specifications, and has multiple application formats.

    zrc-location-icon Use Cases zrc-location-icon Application Formats zrc-location-icon Product Specs zrc-location-icon Product Documentation
    Recommended Uses
    The dried film of Gavilite is 95% metallic zinc. Because of the uniqueness of the formulation, Gavilite is the only coating of its type to be recognized under the Component Program of Underwriter's Laboratories, Inc. Galvilite is widely used without topcoat in place of hot-dip galvanizing. It’s specially formulated for:
    Hot-Dip Galvanizing Repair & Regalvanizing It’s a flexible option for repair of worn hot-dip galvanized materials.
    Weldments Repair Our original compound can be used to repair weldments.
    Long-Term Protection It’s proven to be effective long-term protection for: structural steel, water and waste facilities, power plants, transmission towers and antennae, steel decking and bridges, and numerous OEM uses.
    Inorganic Zinc Coatings Repair ZRC is also effective for inorganic zinc coatings repair.
    Galvalume® and Zinc Metallizing Galvilite can be used for Galvalume® and zinc metalizing projects.

    Flexible Application Formats


    Unlike hot-dip galvanizing, Galvilite is portable, flexible protection that can be applied in a variety of formats. It’s meant to be applied to properly prepared carbon steel, cast iron, hot-dip galvanized, and aluminum surfaces.
    Brush, Roller, and Aerosol
    Spray (Low Pressure Compressor)
    Spray (Airless)
    Roller

    Brush, Roller, and Aerosol

    Apply as received in the container. For brush application, we recommend only 100% Natural Chinese Bristle brushes. For roller application, we recommend rollers with a 3/8” nap, made of mohair or lambs wool (sheepskin).
    Paint Sprayer

    Spray (Low Pressure Compressor)

    ZRC can also be applied as a spray. Notes:

    • Atomized Air Pressure 50 Lbs (1.3 kg/cm²)

    • Fluid Pressure:15 to 20 Lbs (0.4-0.6 kg/cm²)

    • Orifice of Tip: 0.080 inches (0.20 cm)

    • Viscosity Reduction: 4:1 Mineral spirits -OR- 16:1 Xylene
    Worker Using Airless Sprayer

    Spray (Airless)

    Recommended Procedure: Connect hose directly to pump ensuring a hose length of 50 ft. max. Use the least pressure possible. Start at 1500 lbs. (680 kg) and increase as required for good spraying. Notes:



    • Pump: 30:1 Ratio

    • Hose: 1/2" (1.3 cm)(I.D.) Airless Type

    • Orifice of Tip: 60° - .026 in. (0.07 cm)

    • Type of Tip: Tungsten carbide, reversing

    • Filter Screens Complete removal is recommended. However, if screens are employed, use no less than 30 mesh.

    • Viscosity: No reduction required.

    Specifications: ZRC Galvilite Galvanizing Repair

    Here are our product details:

    Specifications
    SSPC Paint Specification 20 – Zinc-Rich Coating: Type II – Organic; Level 1 – equal to or greater than 95% zinc dust by weight present in the dried film
    Zinc Dust Content
    Zinc Dust Content - ASTM D 520 Type III Zinc Dust - .002% maximum lead by weight
    Weight and VOC Notes
    Weight per gallon – not less than 24 lbs. VOC Content — ASTM D 3960, 385 g/l (3.3 lbs per gallon) maximum
    Color and Gloss
    Color and Gloss – Silver with gloss matching appearance of new hot- dip galvanizing
    Manufacturers

    Manufacturers: Subject to compliance with requirements, provide galvanizing compound by one of the following:

    1. Galvilite Galvanizing Repair Compound, ZRC Worldwide

    (www.zrcworldwide.com, (800 831-3275 ))

    1. No known equal.

    Follow manufacturer’s application instructions.

    Manufacturer to provide Certificate of Conformance to above criteria

    Part Numbers

    20010 - Galvilite 12oz Aerosol

    20011 - Galvilite Half Pint

    20012 - Galvilite Quart

    20013 - Galvilite Gallon

    20014 - Galvilite 3.5 gal Pail
